12000SE 150000SE 18000SE
Hensing
Model | DG12000SE | DG15000SE | DG18000SE | |||
Alternator Type | Self-excited | |||||
Frequency (Hz) | 50 | 60 | 50 | 60 | 50 | 60 |
Rated output(KW) | 10 | 10.5 | 11 | 12 | 14 | 15 |
Max.output(KW) | 11 | 11.5 | 11.5 | 12.5 | 15 | 16 |
Rated AC voltage(V) | 110,120,220,230,127/220,120/240,220/380,230/400 | |||||
Power factor(cosφ) | 1/0.8 | |||||
DC output(V/A) | 12/8.3 | |||||
Phase | Single OR Three | |||||
Starting system | Electric | |||||
Noise level(at 7m) (dB) | 78–83 | |||||
Fuel tank capacity(L) | 30 | |||||
electrical machinery(D*L) | 245*130 | 245*140 | 270*180 | |||
Engine Model | 2V88 | 2V92 | 2V95F | |||
Engine Type | Twin-Cylinder,Vertical 4-Cycle,Air-cooled diesel | |||||
Bore*stroke(mm) | 2–88*75 | 2–92*75 | 2–95*98 | |||
Displacement capacity(CC) | 912 | 997 | 1247 | |||
Engine Speed (rpm) | 3000 | 3600 | 3600 | 3000 | 3600 | 3600 |
Starting System | Electric start | |||||
Lubrication Oil Volume (L) | 3 | |||||
Combustion system | Direct injection | |||||
Lubrication System | Forced lubrication via trochoids pump | |||||
Cooling System | Forced–air cooling | |||||
Structure Type | Closed,Silent | |||||
PACKING Dimension(LWH)(mm) | 1120*640*870 | 1190*730*950 | ||||
Gross weight(KG) | 265KG | 275KG | 297KG | |||
