2500CLE-18000CLE
Hensing
Model | D2500C | D4000C | D6500C | D7500C | D8000CC |
Rated Frequency [Hz] | 50 60 | 50 60 | 50 60 | 50 60 | 50 60 |
Rated Voltage [v] | 220,230,240,110/220,115/230,120/240 | 220,230,240,110/220,115/230,120/240,220/380,230/400,240/415 | |||
Rated Output Power（kw) | 1.8 2.2 | 2.8 3.0 | 4.5 5.0 | 5.0 5.5 | 6.0 6.5 |
Max Output Power (kw) | 2.0 2.5 | 3.0 3.3 | 5.0 5.5 | 5.5 6.0 | 6.5 7.0 |
Phase Number | Single/Three | ||||
Excitation Transistorized | Self-excitation , brush | ||||
Power Factor Cos Φ | 1 | 1.0(0.8) | |||
Insulation Grade | F | ||||
Motor Size | 160*85 | 190*85 | 190*130 | 190*140 | 190*158 |
Battery | 17AH | 24AH | 30AH | 30AH | 36AH |
Fuel Tank Capacity [L] | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
Frame Type | 25 25mm Round tube frame 25 25mm | 25 25mm Round tube frame 25 25mm | 25 25mm Round tube frame 25 25mm | 25 25mm Round tube frame 25 25mm | 25 25mm Squre tube frame 25 25mm |
Engine Model | 170FE | 178FE | 186FA | 188FA | 192F |
170FE | 178FE | 186FAE | 188FAE | 192FE | |
Starting System | Recoil starter ; Electric starter | ||||
Engine Type | 1-Cylinder ,4-Stroke ,Air-cooled, Veritical | ||||
Broke * Stroke [mm] | 70 * 55 | 78 * 62 | 86 * 72 | 88 * 75 | 92 * 75 |
Displacement [L] | 0.211 | 0.296 | 0.418 | 0.456 | 0.498 |
Compression Ratio | 20 | 20 | 19.5 | 19.5 | 19.5 |
Rated Rotation Speed [rpm] | 3000 3600 | 3000 3600 | 3000 3600 | 3000 3600 | 3000 3600 |
Rated Power [Kw] | 2.5 2.8 | 3.68 4.0 | 5.9 6.5 | 6.7 7.5 | 7.5 8.2 |
Lube [L] | 0.75 | 1.1 | 1.65 | 1.7 | 1.7 |
Fuel Consumption [g/kwh] | 275 280 | 275 280 | 275 280 | 275 280 | 275 280 |
Fuel Type | 0#(summer), -10#(winter), Diesel oil | ||||
Lube | SAE10W30 ( above CD grade ) | ||||
Optional Standard | ATS | ||||
Remote control | |||||
Heater/emergency stop button/pressure reducing valve cable | |||||
Digital Smart Panel | |||||
Wheels and handles | |||||
