XHX7500
Hensing
Model | D6500 | D7000 | D7500 | D8000 | D8500 | D9000 | D9500 |
Rated Frequency [Hz] | 50 60 | 50 60 | 50 60 | 50 60 | 50 60 | 50 | 50 |
Rated Voltage [V] | 220,230,240,110/220,115/230,120/240,220/380,230/400,240/415 | ||||||
Rated Output Power(kw) | 4.5 5.0 | 5.0 5.5 | 6.0 6.5 | 6.5 6.8 | 8.0 8.5 | 9 | 9 |
Max Output Power(kw) | 5.0 5.5 | 5.5 6.0 | 6.5 7.0 | 7.0 7.3 | 8.5 8.8 | 9.5 | 9.5 |
DC Output | 12V 8.3A | ||||||
Phase Number | Single Phase / Three Phase | ||||||
Excitation Mode | Self-excitation , brush | ||||||
Power Factor Φ | 1.0(0.8) | ||||||
Insulation Grade | F | ||||||
Motor Size | 190*130 | 190*140 | 190*158 | 204*140 | 204*160 | 210*160 | 245*140 |
Battery | 30AH | 30AH | 36AH | 36AH | 36AH | 36AH | 36AH |
Fuel Tank Capacity [L] | 14.5 | 14.5 | 24.0 | 24.0 | 24.0 | 24.0 | 24.0 |
Engine Model | 186FAE | 188FAE | 192FE | 195FE | 1100FE | 1103FE | 1103FE |
Starting System | Electric Starting | ||||||
Engine Type | 1-Cylinder ,4-Stroke, Air-cooled,Veritical | ||||||
Broke * Stroke [mm] | 86*72 | 88*75 | 92*75 | 95*75 | 100*85 | 103*88 | 103*88 |
Displacement | 0.418L | 0.456L | 0.499L | 0.532 | 0.667 | 0.733 | 0.733 |
Compression Ratio | 19.5 | 20 | |||||
Rated Rotation Speed [rpm] | 3000 3600 | 3000 3600 | 3000 3600 | 3000 3600 | 3000 3600 | 3000 | 3000 |
Rated Power [Kw] | 5.8 6.6 | 6.6 6.9 | 7.6 8.6 | 8.0 9.2 | 9.2 9.8 | 10 | 10 |
Lube [L] | 1.65 | 2.5 | 2.5 | 2.5 | |||
Fuel Type | 0#(summer), -10#(winter), diesel oil | ||||||
Lube | SAE10W30 ( above CD grade ) | ||||||
Low Oil Pressure Alarm System | with | ||||||
Optional Standard | ATS | ||||||
Remote control | |||||||
Heater/emergency stop button/pressure reducing valve cable | |||||||
Digital Smart Panel | |||||||
